| Quantity: | |
|---|---|
| Product name | Customized Aluminum Profiles Cupboard Aluminium Profiles Door Frame Aluminum Profile |
| Type | Furniture Handle & Knob |
| Material | aluminum |
| Function | open and close door |
| Color | Customized Color |
| Feature | minimalist,hidden,clean,exquisite |
| Usage | cupboard ,wardrobe,furniture handle |
| Drawing Formats | PRO/E, Auto CAD, Solid Works , UG, CAD / CAM / CAE, PDF |
Our Customized Aluminum Profiles Cupboard Aluminium Profiles Door Frame Aluminum Profile offers versatile structural solutions for architectural and industrial applications. Crafted from 6063-T5 (for general use) and 6061-T6 (for high-strength requirements) alloys, these profiles combine lightweight strength (density 2.7 g/cm³) with excellent corrosion resistance—ideal for window frames, cabinetry, and modular furniture. With customizable cross-sections (from simple rectangles to complex multi-chamber designs) and specialized surface treatments, we deliver bespoke designs that balance aesthetics, functionality, and cost-efficiency.
Achieve tensile strength ≥160 MPa and yield strength ≥110 MPa for load-bearing applications like curtain walls (tested to withstand 2.4 kPa wind pressure) and partition systems .
Integrated thermal breaks (PA66 GF25 material) reduce heat transfer by 40%, enhancing energy efficiency in building envelopes and meeting EU EN 14351-1 standards.
Create unique cross-sectional shapes (e.g., T-slots, hollow channels, decorative profiles) using CNC extrusion dies with ±0.1 mm dimensional control and surface roughness Ra ≤1.6 μm .
Support for multi-chamber profiles (up to 6 chambers) improves sound insulation (STC ≥35 dB) for office partitions and structural rigidity for long-span applications.
Choose from natural anodizing (12–15 μm), hard anodizing (25–50 μm for wear resistance), polyester powder coating (60–80 μm, RAL color matching), and wood grain embossing (12 patterns available)—all compliant with GB/T 3190 and Qualicoat Class 2 standards .
Salt spray resistance up to 1,000 hours (ASTM B117) for outdoor applications like patio doors, sunshades, and garden furniture.
Click-fit connectors and hidden fasteners enable tool-free installation, reducing on-site labor costs by 30% compared to welded alternatives.
Interchangeable components allow easy reconfiguration for dynamic spaces like exhibition booths, retail displays, and temporary event structures.
Architecture: Energy-efficient window frames (U-value ≤1.2 W/m²K), curtain walls (tested to 1500Pa water resistance), and balcony railings (load capacity 500N/m).
Furniture: Modular kitchen cabinets (with soft-close hinges), office shelving systems (adjustable at 25mm increments), and room dividers (acoustic rating ≥25 dB).
Automotive: Lightweight trailer frames (weight reduction 40% vs steel), EV charging station enclosures (IP65 rated), and battery pack housings.
Industrial: Conveyor guide rails (wear-resistant coating), machine guards (safety compliant to ISO 13857), and material handling racks (static load 200kg/m).
Precision Cutting: ±0.2 mm tolerance on lengths from 0.5–12 meters using CNC sawing machines, with no minimum order quantity for standard profiles.
Specialized Coatings: PVDF fluorocarbon spraying (Kynar 500) for UV resistance (color retention ≥95% after 10 years outdoor exposure) and anti-fingerprint coatings for high-touch surfaces.
Hardware Integration: Pre-drilled holes (±0.1mm position accuracy), mitered corners (45°±0.5°), and slot machining for seamless fitting of hinges, handles, locks, and glass panels.
